R51 GNSS Receiver
The R51 versatile monitoring receiver integrates a large-capacity battery, storage card, attitude sensor, Bluetooth, dual 4G modules, and a high-precision positioning board. With an IP67 protection rating, it is designed to operate reliably in harsh environments. The device supports real-time monitoring, intelligent analysis, online supervision, and early warning functions. It can also serve as a ground-based augmentation network base station, offering flexibility for multiple uses.
Multi-constellation and multi-frequency positioning
High precision with low power consumption
IP67 protection rating
Built-in solar power supply
Remote configuration and upgrade
Large-capacity storage with data loop recording
Product Features
High-Precision Positioning
Utilizes multi-constellation and multi-frequency systems like BDS, GPS, GLONASS, and Galileo to maintain high accuracy in various complex environments.
High Integration Design
The all-in-one design integrates multiple functional modules, reducing dependence on external devices and enhancing overall system performance and reliability.
Powerful Power Supply System
Supports multiple power sources, including mains electricity, batteries, and solar power, ensuring stable operation across different application scenarios.
Remote Management and Monitoring
Supports remote configuration and upgrades, allowing users to monitor device status and data in real-time through the platform, improving management efficiency.
Product Parameters
Signal Tracking: BDS: B1I/B2I/B3I/B1C/B2a/B2b GPS: L1C/A/L1C/L2C/L2P（Y）/L5 GLONASS: G1/G2/G3 Galileo: E1/E5a/E5b/E6 QZSS: L1C/A/L1C/L2C/L5 NavIC: L5 SBAS: L1C/A Cold Start Time: <12s Initialization Time: <5s (typical) RTK Initialization Reliability: >99.9% Reacquisition Time: <1s single point positioning: Horizontal: 1.5m Vertical: 2.5m | RTK Accuracy: 8mm+1ppm(RMS) 15mm+1ppm(RMS) Static Accuracy: 2.5mm+1ppm(RMS) 5mm+1ppm(RMS) Power consumption：1.5 to 4.0 W Supply voltage: 9 to 36V DC, supporting power-on auto-start, reverse connection protection Operating temperature： -45°C to +75°C Storage temperature： -55°C to +85°C Physical dimensions： φ196.7mm × 129.5mm Weight： <1.65kg | Ingress protection rating： IP67, floatable Impact and vibration： Resistant to 2m drops Indicator： 6 LED indicators Data output： NMEA-0183, binary code Data refresh rate： 1 to 20Hz optional Baud rate： 9600 to 460800 Interfaces： 9-core aviation (1 solar, 1 battery, 1 grid, and 1 RS232), 1 SIM card slot Differential format： RTCM3.2 Communication： GSM 4G module Bluetooth： BT4.0, backward compatible with BT2.X Network： TCP, NTRIP |
